Pressure Vessels Heads app is very helpful for Calculation of Blank Diameter, Weight, Crown Radius, Knuckle Radius, and Height of pressure Vessel heads such as Torispherical Head, ellipsoidal head and Hemispherical head.

This Tool is also Used to Calculate Template Layout Marking for 2:1 Ellipsoidal Dish ends. It is also applicable for Pressure Vessel End Caps, Dish Ends, Formed Heads and End Closure etc.

Click here to Download App for Android Device.

Click here to Download App for Apple Device.

Pressure Vessels Heads App Having Following Types of Calculators:

  1. Flat Dish End Blank Diameter Calculator.
  2. Toripherical Dish Ends Blank Diameter Calculator.
  3. Ellipsoidal Dish Ends Blank Diameter Calculator.
  4. Hemispherical Dish Blank Diameter Calculator.
  5. Ellipsoidal Head Template Layout Marking Calculator.

Pressure Vessels Heads app is designed for following Heads.

  1. 10% Torispherical head or Torispherical dish Ends.
  2. 2: 1 Ellipsoidal head or Ellipsoidal Dish Ends.
  3. Hemispherical heads or Hemispherical Dish Ends.

All dimensional Input Should be required in this application is in MM or Metric System.

How To Use Pressure Vessels Heads App :

1. Flat Heads Blank Calculator :

This Tool is used to Calculates All Terms of Flat Dish End such as Dish End Height, Dish End Blank Diameter and Dish End Weight.

In this Application you have to provide required inputs data of Flat Dish ends such as Dish end Inside Diameter in mm, Dish End Knuckle radius in mm, Dish End Straight Face in mm, Dish End Thickness in mm and Dish end Specific Gravity. Alternately, If you don’t know it then Select Material From List. After that you have to Click on Calculate Button. After that you will get result output.

This app gives output as Flat Dish End Height in mm, Flat Dish end Blank Diameter Required in mm and Flat Dish End Weight in Kg. If Your Material is not available in Material Selection List. Then Please enter Specific Gravity of Material Manually in Specific Gravity Input Field.

2. Ellipsoidal Heads Blank Calculator :

This Tool is used to Calculates All Terms of Ellipsoidal Dish End such as Dish end Crown Radius, Knuckle radius, Dish End Height without Straight Face, Dish End Height with Straight face, Dish End Blank Diameter and Dish End Weight.

In this Application you have to provide required inputs data of Ellipsoidal Dish ends is Dish End Inside Diameter in mm, Dish End Straight Face in mm, Dish End Thickness in mm and Dish end Specific Gravity. If you don’t have this then Select Material From List then Click on Calculate Button. After that you will get result output. This app gives output as Dish End Crown radius in mm, Knuckle Radius in mm, Height without Straight Face in mm, Height With Straight Face in mm, Blank Diameter Required in mm and Dish End Weight in Kg.

If Your Material is not available in Material Selection List then please enter Specific Gravity of Material Manually in Specific Gravity Input Field.

3. Torispherical Heads Blank Calculator :

It is used for Calculating Torispherical Dish End Crown Radius, Knuckle Radius, Heights, Blank Diameter and Weights. To use this calculator Follow me Process as Ellipsoidal Heads Calculator.

4. Hemispherical Heads Blank Calculator :

It is used for Calculating Hemi Dish End Radius, Dish End Heights, Blank Diameter and Dish End Weights. To use this calculator Follow me Process as Ellipsoidal Heads Calculator.

5. Ellipsoidal Head Template Layout Marker:

It Used to Generate Elliptical Head Template Layout Marking Coordinates for faster Layout.

It is useful for Fabrication Engineer for Getting All Term related to Pressure Vessels End Caps, Pressure Vessel Heads or Pressure Vessels Dish Ends.

In this App use can also Calculates Weight of Dish Ends for Different Types of Materials. Some of the materials are Carbon steel, Stainless Steel, Aluminium, brass , bronze, Copper, Lead etc. materials.

Blank Diameter calculated by This Tool is useful for Estimation and costing purpose. So that while Cutting Blank size of the above Dish End please consult with your head manufacture for desired Accuracy.

Click here to Download App for Android Device

Click here to Download App for Apple Device

If you want other fabrication apps for your daily fabrication activity then Click here…

If you want sharpen your knowledge in Pressure Vessels Heads then learn from Our 21 Days Video Course for Becoming Expert in Pressure Vessels Heads or Dish Ends or Formed Heads or End Closure or End Cap. To Get in Discounted Price Click here…
